WEG, AC Motor, 01018ET3E215T-W22, 10 HP, 1800 RPM, 213, 5T, Three Phase, 230/460 V, 60 Hz (01018ET3E215T-W22)
- Model:
- 01018ET3E215T-W22
- Brand:
- WEG
- Product Condition:
- New
- Motor Type:
- General Purpose
- Horsepower Rating:
- 10 HP
- Synchronous RPM:
- 1800 RPM
- Rated Supply Voltage:
- 230/460 V
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
- Rated Voltage:
- 230 V
- Rated Voltage:
- 460 V
- Phase:
- Three Phase
- Service Factor:
- 1.25
- Efficiency:
- 91.7%
- Construction:
- Cast Iron
- C Dimension:
- 19.517
- Mounting Type:
- Foot Mount
- Rated Input Frequency:
- 60 Hz
- Motor Full Load Amps:
- 12.4 A
