S100-02S21-0B0000 Nidec Drives/Control Techniques, Commander S, 0.33HP, 240V, Single Phase (S100-02S21-0B0000)

Brand:
Control Techniques
Model:
S100-02S21-0B0000
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added

Commander S microdrives are perfect for a variety of applications. They're simple to program and use.

S100-02S21-0B0000

  • 0.33 Horsepower
  • 1.4 Amps
  • 240 Volt
  • IP20
  • 1 Phase Input - 3 Phase Output
  • ModbusRTU communication
  • NFC communication and Marshal app programming
  • 5-year manufacturer warranty
Write a Review

Technical Specifications

Series:
Commander S
Model:
S100-02S21-0B0000
Brand:
Control Techniques
Product Condition:
New
Warranty:
5 Years
Horsepower Rating:
0.33 HP
HP Rating @ 150% OL:
0.33 HP
Rated Amps:
1.4 A
Amp Rating @ 150% OL:
1.4 A
Rated Voltage:
240 V
Rated Input Frequency:
60 Hz
Output Voltage:
240 V
Output Amperage Rating:
1.4 A
Phase Rating:
1 Phase Input - 3 Phase Output
Phase:
Single Phase
Ambient Tempurature Rating:
40 °C
Enclosure Rating:
IP 20
Frame Size:
2
Communication Protocol:
Modbus RTU
Height:
7.56 in
Width:
2.70 in
Depth:
5.20 in

Product Information

Control Techniques Commander S Series

The Commander S microdrive from Nidec Drives is a simple, easy-to-install VFD for small applications. With the Marshal App and NFC communication, it's easy to program and control. With a standard 150% heavy duty overload rating and multiple voltage and phase choices, it's ready for most small applications.

Standard Features

  • 5 year manufacturer warranty
  • 150% heavy duty overload rating
  • 120V, 240V, and 480V input options
  • Single- and three-phase input options
  • NFC communication and configuration through the Marshal app
