200HP 460V Control Techniques VFD, Inverter, AC Drive M700-09402240A (M700-09402240A)
Online Price:
Call for Price
The M600 is designed to optimize machine performance, using sensorless permanent magnet motor control and sensorless induction for dynamic and efficient machine operation. An optional encoder port can be used for precise closed loop velocity applications and digital lock/frequency following. Additional I/O, global fieldbus communications and encoder feedback options maximize system connectivity and flexibility. Typical applications include:
![]() ![]() This Item
|
![]() ![]() |
![]() ![]() |
![]() ![]() |
![]() ![]() |
![]() ![]() |
![]() ![]() |
|
200HP 460V Control Techniques VFD, Inverter, AC Drive M600-09402240A (M600-09402240A) | 150HP 460V Mitsubishi F800E VFD, Inverter, AC Drive FR-F840-02160-E3U6 (FR-F840-02160-E3U6) | 175HP, 480V, Galt Electric G500 Legacy VFD (G540-02150UL-01) | 150HP, 480V, Galt Electric G500 VFD (G540-01800UL-03) | 175HP, 480V, Galt Electric G500 VFD (G540-02150UL-03) | 200HP, 480V, Galt Electric G500 VFD (G540-02600UL-03) | 150HP 460V LS Electric H100 VFD, Inverter, AC Drive LSLV1100H100-4COFD (LSLV1100H100-4COFD) | |
Ratings | |||||||
Price |
Call for Price
|
$9635.2
|
$7167.95
|
$6647.36
|
$7169.36
|
$8336.21
|
$6138.03
|
Model |
M600-09402240A
|
FR-F840-02160-E3U6
|
G540-02150UL-01
|
G540-01800UL-03
|
G540-02150UL-03
|
G540-02600UL-03
|
LSLV1100H100-4COFD
|
Brand |
Control Techniques
|
MITSUBISHI
|
GALT ELECTRIC
|
GALT ELECTRIC
|
GALT ELECTRIC
|
GALT ELECTRIC
|
LS
|
Product Condition |
New
|
New
|
New
|
New
|
New
|
New
|
New
|
Warranty |
|
1 Year
|
3 Years
|
3 Years
|
3 Years
|
3 Years
|
2 Year
|
HP Rating @ 120% OL |
|
150 HP
|
175 HP
|
150 HP
|
175 HP
|
200 HP
|
150 HP
|
HP Rating @ 150% OL |
150 HP
|
|
150 HP
|
100 HP
|
150 HP
|
150 HP
|
|
Amp Rating @ 120% OL |
|
180 A
|
215 A
|
180 A
|
215 A
|
260 A
|
223 A
|
Amp Rating @ 150% OL |
224 A
|
|
180 A
|
150 A
|
180 A
|
215 A
|
|
Rated Voltage |
460 V
|
460 V
|
460 V, 480 V
|
460 V, 480 V
|
460 V, 480 V
|
460 V, 480 V
|
460 V
|
Output Amperage Rating |
224 A
|
216 A
|
180 A
|
150 A
|
215 A
|
215 A
|
223 A
|
Phase Rating |
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
3 Phase Input - 3 Phase Output
|
Constant Torque / Variable Torque |
|
Variable Torque
|
Variable Torque/Constant Torque
|
Variable Torque/Constant Torque
|
Variable Torque/Constant Torque
|
Variable Torque/Constant Torque
|
Variable Torque/Constant Torque
|
Phase |
Three Phase
|
Three Phase
|
Three Phase
|
Three Phase
|
Three Phase
|
Three Phase
|
Three Phase
|
Enclosure Rating |
IP 20
|
IP 00
|
IP 20
|
IP 20
|
IP 20
|
IP 20
|
IP 20
|
Series |
M600
|
F800E
|
G500
|
G500
|
G500
|
G500
|
|
Ambient Tempurature Rating |
|
|
40 °C
|
40 °C
|
40 °C
|
40 °C
|
|
Rated Amps |
224 A, 266 A
|
180 A, 216 A
|
215 A
|
180 A
|
215 A
|
260 A
|
223 A
|
Horsepower Rating |
150 HP, 200 HP
|
150 HP
|
150 HP, 175 HP
|
100 HP, 150 HP
|
150 HP, 175 HP
|
150 HP, 200 HP
|
150 HP
|
Frame Size |
|
J
|
6(B)
|
6(B)
|
6(B)
|
7
|
|
HP Rating @ 110% OL |
200 HP
|
150 HP
|
|
|
|
|
|
Amp Rating @ 110% OL |
266 A
|
216 A
|
|
|
|
|
|
Rated Input Frequency |
|
60 Hz
|
|
|
|
|
60 Hz
|
Output Voltage |
460 V
|
460 V
|
|
|
|
|
460 V
|
Communication Protocol |
|
Modbus TCP/IP, CC-Link IE
|
|
|
|
|
|
