ROBICON W120CP clean power 18-pulse drives from Siemens are the result of a combination of Siemens SINAMICS and ROBICON technology. The W120CP clean power drives are now available after over 20 years of quality and expertise to produce an exceptional drive. The 18-pulse technology provides clean power to meet the low harmonic requirements of IEEE 519-1992 at the VFD input terminals. The drive can be operated in either Volts/Hertz or sensorless vector control modes. The W120 has wall mount or floor standing options.
Manufacturer
Siemens
Series
Robicon W120CP
Model
6SL37103BJ318AR0
Condition
New
1 Year Manufacture Warranty
Constant/Variable Torque
CT/VT
Horsepower?
LO: 125 HP
HO: 100 HP
Maximum Amps?
LO: 160 A
HO: 145 A
Input
3 Phase
460-480V 50Hz/60Hz
Output
3 Phase
460-480V 50Hz/60Hz
Enclosure Rating
NEMA 1
Features
Power Module PM 240 (18-pulse diode rectifier)
Circuit breaker disconnect
Integral braking chopper
Frame Size
F
Dimensions
Height: 94 in
Width: 30 in
Depth: 24 in
