  • US Motors (Nidec) US Motors (Nidec), AC Motor, D7P2D, 7.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 213T (D7P2D)

    US Motors (Nidec), AC Motor, D7P2D, 7.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 213T (D7P2D)

    • Model:
      R341
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      7.5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      213T
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Open Drip Proof (ODP)
    • Motor Design Class:
      B
    • Full Load Torque:
      22.3
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.15
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      91%
    • Construction:
      Rolled Steel
    • C Dimension:
      16
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      20.2-18.5/9.3 A
    • Weight:
      105.00 LBS
    In Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, D20P2D, 20 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 256T (D20P2D)

    US Motors (Nidec), AC Motor, D20P2D, 20 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 256T (D20P2D)

    • Model:
      FP91
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      20 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      256T
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Open Drip Proof (ODP)
    • Motor Design Class:
      B
    • Full Load Torque:
      59.2
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.15
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      93%
    • C Dimension:
      23.2
    • Bearing Type:
      6309-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      52-47/23.6 A
    • Weight:
      160.00 LBS
    In Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, D100P1ES, 100 HP, 3600 RPM, Three Phase, 230/460 & 190/380 V, 60 , 50 Hz, 365TS (D100P1ES)

    US Motors (Nidec), AC Motor, D100P1ES, 100 HP, 3600 RPM, Three Phase, 230/460 & 190/380 V, 60 , 50 Hz, 365TS (D100P1ES)

    • Model:
      D100P1ES
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      100 HP
    • Synchronous RPM:
      3600 RPM
    • Frame Size:
      365TS
    • Rated Supply Voltage:
      230/460 & 190/380 V
    • Motor Enclosure Type:
      Open Drip Proof (ODP)
    • Motor Design Class:
      B
    • Full Load Torque:
      147.3
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.15
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      94.1%
    • Construction:
      Cast Iron
    • C Dimension:
      27.5
    • Bearing Type:
      6212-2Z-J
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      224/112 A
    • Weight:
      600.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U5P2DCR, 5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 184TC (U5P2DCR)

    US Motors (Nidec), AC Motor, U5P2DCR, 5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 184TC (U5P2DCR)

    • Model:
      U5P2DCR
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      184TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      14.9
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      90.2%
    • C Dimension:
      16.8
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      13.6-12.3/6.2 A
    • Weight:
      80.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U5P2DC, 5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 184TC (U5P2DC)

    US Motors (Nidec), AC Motor, U5P2DC, 5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 184TC (U5P2DC)

    • Model:
      U5P2DC
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      184TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      14.9
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      90.2%
    • Construction:
      Aluminum
    • C Dimension:
      16.9
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      13.6-12.3/6.2 A
    • Weight:
      80.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U3P2DCR, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182TC (U3P2DCR)

    US Motors (Nidec), AC Motor, U3P2DCR, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182TC (U3P2DCR)

    • Model:
      U3P2DCR
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      3 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      182TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      8.9
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      89.5%
    • C Dimension:
      16.1
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      8.4-7.8/3.9 A
    • Weight:
      60.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U3P2DC, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182TC (U3P2DC)

    US Motors (Nidec), AC Motor, U3P2DC, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182TC (U3P2DC)

    • Model:
      U3P2DC
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      3 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      182TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      8.9
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      89.5%
    • Construction:
      Aluminum
    • C Dimension:
      16.1
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      8.4-7.8/3.9 A
    • Weight:
      70.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U3P2D, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182T (U3P2D)

    US Motors (Nidec), AC Motor, U3P2D, 3 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182T (U3P2D)

    • Model:
      U3P2D
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      3 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      182T
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      8.9
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      89.5%
    • Construction:
      Aluminum
    • C Dimension:
      16.5
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      8.4-7.8/3.9 A
    • Weight:
      60.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U3P1D, 3 HP, 3600 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182T (U3P1D)

    US Motors (Nidec), AC Motor, U3P1D, 3 HP, 3600 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 182T (U3P1D)

    • Model:
      U3P1D
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      3 HP
    • Synchronous RPM:
      3600 RPM
    • Frame Size:
      182T
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      4.4
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      87.5%
    • Construction:
      Aluminum
    • C Dimension:
      16.1
    • Bearing Type:
      6205-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      8.4-7.8/3.9 A
    • Weight:
      60.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U32P2DFCR, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 56C (U32P2DFCR)

    US Motors (Nidec), AC Motor, U32P2DFCR, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 56C (U32P2DFCR)

    • Model:
      U32P2DFCR
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      1.5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      56C
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      4.5
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      86.5%
    • C Dimension:
      13
    • Bearing Type:
      6203-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      4.5-4.3/2.1 A
    • Weight:
      30.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U32P2DCR, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 145TC (U32P2DCR)

    US Motors (Nidec), AC Motor, U32P2DCR, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 145TC (U32P2DCR)

    • Model:
      U32P2DCR
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      1.5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      145TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      4.5
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      86.5%
    • C Dimension:
      13.1
    • Bearing Type:
      6203-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      4.5-4.3/2.1 A
    • Weight:
      35.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
  • US Motors (Nidec) US Motors (Nidec), AC Motor, U32P2DC, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 145TC (U32P2DC)

    US Motors (Nidec), AC Motor, U32P2DC, 1.5 HP, 1800 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 145TC (U32P2DC)

    • Model:
      U32P2DC
    • Brand:
      US Motors (Nidec)
    • Product Condition:
      New
    • Motor Type:
      General Purpose
    • Horsepower Rating:
      1.5 HP
    • Synchronous RPM:
      1800 RPM
    • Frame Size:
      145TC
    • Rated Supply Voltage:
      208-230/460 & 190/380 V
    • Motor Enclosure Type:
      Totally Enclosed Fan Cooled (TEFC)
    • Motor Design Class:
      B
    • Full Load Torque:
      4.5
    • Rated Voltage:
      208 V
    • Rated Voltage:
      230 V
    • Rated Voltage:
      380 V
    • Rated Voltage:
      460 V
    • Phase:
      Three Phase
    • Service Factor:
      1.25
    • Insulation Class:
      F
    • Duty Cycle:
      Continuous
    • Efficiency:
      86.5%
    • Construction:
      Rolled Steel
    • C Dimension:
      13.1
    • Bearing Type:
      6203-2Z-J/C3
    • Rated Input Frequency:
      60 Hz
    • Rated Input Frequency:
      50 Hz
    • Motor Full Load Amps:
      4.5-4.3/2.1 A
    • Weight:
      35.00 LBS
    Out Of Stock
    Call for Price
    Adding to cart… The item has been added
    VIEW DETAILS
