US Motors (Nidec), AC Motor, HD40P2E, 40 HP, 1800 RPM, Three Phase, 230/460 & 200/400 V, 60 , 50 Hz, 324T (HD40P2E)
- Model:
- GC03
- Brand:
- US Motors (Nidec)
- Product Condition:
- New
- Motor Type:
- Severe Duty
- Horsepower Rating:
- 40 HP
- Synchronous RPM:
- 1800 RPM
- Frame Size:
- 324T
- Rated Supply Voltage:
- 230/460 & 200/400 V
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
- Motor Design Class:
- B
- Full Load Torque:
- 118.1
- Rated Voltage:
- 208 V
- Rated Voltage:
- 230 V
- Rated Voltage:
- 460 V
- Phase:
- Three Phase
- Service Factor:
- 1.15
- Insulation Class:
- F
- Duty Cycle:
- Continuous
- Efficiency:
- 94.1%
- Construction:
- Cast Iron
- Bearing Type:
- 6211-2Z-J/C3
- Rated Input Frequency:
- 60 Hz
- Rated Input Frequency:
- 50 Hz
- Motor Full Load Amps:
- 92/46 A
- Weight:
- 450.00 LBS
