Pressure Transmitter, 0-300 PSI gauge, 4-20mA, 1%
Model: GPX4511-300PSIG-E-B4-C6
Condition: New
Technical Specifications
| Series | GPX |
|---|---|
| Brand | GALT ELECTRIC |
| Pressure Range | 0-300 PSI |
| Burst Pressure Rating | 1500PSIg |
| Pressure Rating | 300PSI |
| Display Type | display |
| Sensor Input Voltage Rating | 8-DC V |
| Sensor Media Compatability | Media Compatible with 17-4PH SS |
| Sensor Housing Material | SS 304 |
| Operating Tempurature | -40-125 C |
| Output Signal | .5-4.5 Vdc (3 wire) |
| Sensor Cable Connection | M12 Connector |
| Sensor Process Connection | 1/4" NPT |
| Sensor Accuracy Rating | 1.00% |
| Enclosure Rating | IP 65 |
| Product Condition | New |
| Overpressure Rating | 600PSIg |
| Tempurature Compensation | -10-80 C |
| Model | GPX4511-300PSIG-E-B4-C6 |
| Warranty | 1 Year |
Product Information
GALT ELECTRIC GPX Series
Pressure Transmitter, 0-300 PSI gauge, 4-20mA, 1%, 1/4" NPT, w/ M12 connector
