Technical Specifications
Model:
GDP05006-365T-K
Brand:
GALT ELECTRIC
Product Condition:
New
Warranty:
3 Years
Horsepower Rating:
50 HP
Synchronous RPM:
1200 RPM
Frame Size:
365T
Motor Enclosure Type:
Open Drip Proof (ODP)
Full Load Torque:
222.6
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
460 V
Service Factor:
1.25
Insulation Class:
F
Duty Cycle:
Continuous
Power Factor:
0.83
Efficiency:
94.1%
Construction:
Cast Iron
C Dimension:
29.3
Rated Input Frequency:
60 Hz
Rated Amps:
63 A
Phase:
Three Phase
Series:
GDP
