US Motors (Nidec), AC Motor, U1P3GFC, 1 HP, 1200 RPM, Three Phase, 575 V, 60 Hz, 56C (U1P3GFC)
- Model:
- U1P3GFC
- Brand:
- US Motors (Nidec)
- Product Condition:
- New
- Motor Type:
- General Purpose
- Horsepower Rating:
- 1 HP
- Synchronous RPM:
- 1200 RPM
- Rated RPM:
- 1155 RPM
- Frame Size:
- 56C
- Rated Supply Voltage:
- 575 V
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
- Motor Design Class:
- B
- Full Load Torque:
- 4.5
- Rated Voltage:
- 575 V
- Phase:
- Three Phase
- Service Factor:
- 1.25
- Insulation Class:
- F
- Duty Cycle:
- Continuous
- Efficiency:
- 82.5%
- Construction:
- Aluminum
- Bearing Type:
- 6203-2Z-J/C3
- Rated Input Frequency:
- 60 Hz
- Motor Full Load Amps:
- 1.4 A
- Weight:
- 30.00 LBS
