Technical Specifications
Model:
GPT0030-2-182JM-K
Brand:
GALT ELECTRIC
Product Condition:
New
Warranty:
3 Years
Rated RPM:
3600 RPM
Ambient Tempurature Rating:
40 °C
Phase:
Three Phase
Service Factor:
1.25
Insulation Class:
F
Duty Cycle:
Continuous
Power Factor:
0.85
Efficiency:
86.5%
C Dimension:
16.1
Horsepower Rating:
3 HP
Synchronous RPM:
3600 RPM
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Rated Voltage:
230 V
Rated Voltage:
460 V
Construction:
Cast Iron
Rated Input Frequency:
60 Hz
Rated Amps:
3.8 A
Frame Size:
143/5JM
Frame Size:
143JM
Frame Size:
145JM
Series:
GPT
