US Motors (Nidec), AC Motor, EEQ500, 5 HP, 3600 RPM, Single Phase, 230 V, 60 Hz, 184JMZ (EEQ500)

Brand:
US Motors (Nidec)
Model:
EEQ500
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
Write a Review

Technical Specifications

Model:
EEQ500
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Pool
Horsepower Rating:
5 HP
Synchronous RPM:
3600 RPM
Rated RPM:
3550 RPM
Frame Size:
184JMZ
Rated Supply Voltage:
230 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Motor Design Class:
L
Rated Voltage:
230 V
Phase:
Single Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
88%
Construction:
Rolled Steel
C Dimension:
19.6
Bearing Type:
6204-2Z-J/C3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
20.0 A

Product Information

US Motors (Nidec) Series

5 HP, 3550 RPM, EEQ500, 230 V, 60 HZ, 184JMZ
