US Motors (Nidec), AC Motor, EE254, 0.5 HP, 3600 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 56C (EE254)

US Motors (Nidec), AC Motor, EE254, 0.5 HP, 3600 RPM, Three Phase, 208-230/460 & 190/380 V, 60 , 50 Hz, 56C (EE254)

Brand:
US Motors (Nidec)
Model:
EE254
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
Write a Review

Technical Specifications

Model:
EE254
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Pump
Horsepower Rating:
0.5 HP
Synchronous RPM:
3600 RPM
Frame Size:
56C
Rated Supply Voltage:
208-230/460 & 190/380 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Full Load Torque:
13.12
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
380 V
Rated Voltage:
460 V
Phase:
Three Phase
Insulation Class:
B
Duty Cycle:
Continuous
C Dimension:
10.8
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
2.1-2.2/1.1 A

Product Information

US Motors (Nidec) Series

1/2 HP, 3450 & 2850 RPM, EE254, 208-230/460 & 190/380 V, 60 & 50 HZ, 56C
