US Motors (Nidec), AC Motor, D34CA3JH9, 0.75 HP, 1200 RPM, Single Phase, 115/208-230 V, 60 Hz, 56H (D34CA3JH9)

US Motors (Nidec), AC Motor, D34CA3JH9, 0.75 HP, 1200 RPM, Single Phase, 115/208-230 V, 60 Hz, 56H (D34CA3JH9)

Brand:
US Motors (Nidec)
Model:
D34CA3JH9
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
Write a Review

Technical Specifications

Model:
D34CA3JH9
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
0.75 HP
Synchronous RPM:
1200 RPM
Rated RPM:
1140 RPM
Frame Size:
56H
Rated Supply Voltage:
115/208-230 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Motor Design Class:
L
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1.15
Insulation Class:
B
Duty Cycle:
Continuous
Efficiency:
70%
C Dimension:
13.3
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
10.6/5.4-5.3 A

Product Information

US Motors (Nidec) Series

3/4 HP, 1140 RPM, D34CA3JH9, 115/208-230 V, 60 HZ, 56H
