US Motors (Nidec), AC Motor, D150P2FS, 150 HP, 1800 RPM, Three Phase, 380, 460 V, 60 , 50 Hz, 444TS (D150P2FS)

Brand:
US Motors (Nidec)
Model:
D150P2FS
Condition:
New
0 Customer Reviews
Out Of Stock
Adding to cart… The item has been added

Technical Specifications

Model:
D150P2FS
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
150 HP
Synchronous RPM:
1800 RPM
Frame Size:
444TS
Motor Enclosure Type:
Open Drip Proof (ODP)
Motor Design Class:
B
Full Load Torque:
441.3
Rated Voltage:
380 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
95.8%
Construction:
Cast Iron
C Dimension:
34
Bearing Type:
6313-J
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
170 A

Product Information

US Motors (Nidec) Series

150 HP, 1785 & 1480 RPM, D150P2FS, 460 & 380 V, 60 & 50 HZ, 444TS
