US Motors (Nidec), AC Motor, 8493P, 2 HP, 1800 RPM, Three Phase, 208-230/460 V, 60 Hz, 56H (8493P)

US Motors (Nidec), AC Motor, 8493P, 2 HP, 1800 RPM, Three Phase, 208-230/460 V, 60 Hz, 56H (8493P)

Brand:
US Motors (Nidec)
Model:
8493P
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
Write a Review

Technical Specifications

Model:
8493P
Brand:
US Motors (Nidec)
Product Condition:
New
Horsepower Rating:
2 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1725 RPM
Frame Size:
56H
Rated Supply Voltage:
208-230/460 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
B
Duty Cycle:
Continuous
Efficiency:
86.5%
C Dimension:
12.7
Bearing Type:
BALL
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
6.1-6.3/3.1 A

Product Information

US Motors (Nidec) Series

2 HP, 1725 RPM, 8493P, 208-230/460 V, 60 HZ, 56H
