Technical Specifications
Model:
ODP-2-54050-3HF4N-TN
Brand:
INVERTEK
Product Condition:
New
Warranty:
2 Year
Horsepower Rating:
50 HP
HP Rating @ 150% OL:
50 HP
Rated Amps:
72 A
Amp Rating @ 150% OL:
72 A
Rated Voltage:
460 V
Rated Input Frequency:
60 Hz
Output Voltage:
460 V
Output Amperage Rating:
72 A
Phase Rating:
3 Phase Input - 3 Phase Output
Constant Torque / Variable Torque:
Variable Torque/Constant Torque
Phase:
Three Phase
Enclosure Rating:
IP 55
Frame Size:
5
Series:
Optidrive P2
Height:
21.26 in
Width:
9.25 in
Depth:
10.63 in
