Technical Specifications
Brand:
WEG
Product Condition:
New
Rated Supply Voltage:
460 V
Phase:
Three Phase
Service Factor:
1
Efficiency:
95.7%
C Dimension:
69.381
Motor Full Load Amps:
498 A
Duty Cycle:
Continuous
Motor Type:
General Purpose
Horsepower Rating:
400 HP
Synchronous RPM:
900 RPM
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Rated Voltage:
460 V
Construction:
Cast Iron
Mounting Type:
Foot Mount
Rated Input Frequency:
60 Hz
Product Information
WEG Series
THREE-PHASE GENERAL PURPOSE MOTORS: TEFC, Foot Mount
Severe Duty is standard with all WEG W22 motors. They boast a 1.25 SF resulting in cooler operation. Construction is with high grade FC200 cast iron providing superior mechanical strength and heat dissipation. Motors are balanced to 0.08 inches per second vibration limits. Certified Class 1 Div 2, Groups A, B, C & D; Class II, Div 2, Groups F & G.
