25HP & 30HP 230V Saftronics VFD, Inverter, AC Drive GP102030-1
Brand: Saftronics
Model: GP102030-1
Condition: New Surplus
Compare with similar items
This Item
|
|
|
|
|
|
|
| 25HP & 30HP 230V Saftronics VFD, Inverter, AC Drive GP102030-1 | 30HP 230V Galt Electric G500 VFD, Inverter, AC Drive G520-00800UL-01 | 30HP 230V Galt Electric G300 VFD, Inverter, AC Drive G320-00800UL-01 | 25HP & 30HP 230V Saftronics VFD, Inverter, AC Drive GP102030-1M | 30HP & 40HP 230V Saftronics VFD, Inverter, AC Drive C102030-1 | 30HP 230V Delta VFD-ED VFD, Inverter, AC Drive VFD220ED23S | |
| Ratings | ||||||
| Price |
$1,663.99
|
$1,719.00
|
$1,563.00
|
$999.99
|
$999.99
|
$1,542.50
|
| Free Shipping |
No |
Yes |
Yes |
Yes |
No |
Yes |
| Series |
GP10
|
G500
|
G300
|
GP10
|
C10
|
VFD-ED
|
| Rated Amps |
74 A
|
80 A
|
80 A
|
74 A
|
96 A
|
87 A
|
| Enclosure Rating |
UL Type 1
|
IP 20
|
IP 20
|
UL Type 1
|
UL Type 1
|
IP 20
|
| Brand |
Saftronics
|
GALT ELECTRIC
|
GALT ELECTRIC
|
Saftronics
|
Saftronics
|
Delta
|
| Horsepower Rating |
25 HP, 30 HP
|
30 HP
|
30 HP
|
25 HP, 30 HP
|
30 HP, 40 HP
|
30 HP
|
| Rated Voltage |
230 V
|
230 V
|
230 V
|
230 V
|
230 V
|
230 V
|
| Model |
GP102030-1
|
G520-00800UL-01
|
G320-00800UL-01
|
GP102030-1M
|
C102030-1
|
VFD220ED23S
|
Technical Specifications
| Phase Rating | 3 Phase Input - 3 Phase Output |
|---|---|
| Constant Torque / Variable Torque | Variable Torque |
| Series | GP10 |
| Phase | Three Phase |
| Rated Amps | 74 A |
| Enclosure Rating | UL Type 1 |
| Brand | Saftronics |
| Horsepower Rating | 25 HP, 30 HP |
| Rated Voltage | 230 V |
| Product Condition | New Surplus |
| Output Voltage | 230 V |
| Output Amperage Rating | 74 A |
| HP Rating @ 110% OL | 30 HP |
| HP Rating @ 150% OL | 25 HP |
| Amp Rating @ 110% OL | 78 A |
| Amp Rating @ 150% OL | 74 A |
| Model | GP102030-1 |
| Height | 15.75 in |
| Width | 9.84 in |
| Depth | 7.68 in |
Product Information
Saftronics GP10 Series
The GP10 is manufactured as a general-purpose drive with built-in attributes including speed search, disable reverse operation, automatic restart, and Soft-Switching Technology. This makes the GP10 an optimal drive for fans or pumps.
Standard Features
- Both open loop (Sensorless) vector and Volts / Hertz control methods
- ?0.2% speed control accuracy
- Motor auto tuning including full dynamic tuning (spinning motor), static tuning (loaded motor, not spinning), and On-line tuning (continuous tuning while running)
- Graphic back-lit LCD keypad with digital LEDs
- Copy function
- Soft Switching Technology to eliminate output filters
- PID control
- Smart speed search
- Two second control power ride through
- Serial communication (RS485 Modbus Standard; LonWorks, DeviceNet, Metasys N2, Profibus-DP, Canbus and Interbus-S optional)
- Built in dynamic breaking
- Programmable I/O
- Overtorque detection
- Dual motor parameter table
- Saflink compatible
- Uniform programming parameters with VG10
