US Motors (Nidec), AC Motor, 1862PEP, 0.5 HP, 1200 RPM, Single Phase, 208-230 V, 60 , 50 Hz, 48Y (1862PEP)

US Motors (Nidec), AC Motor, 1862PEP, 0.5 HP, 1200 RPM, Single Phase, 208-230 V, 60 , 50 Hz, 48Y (1862PEP)

Brand:
US Motors (Nidec)
Model:
1862PEP
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
Write a Review

Technical Specifications

Model:
1862PEP
Brand:
US Motors (Nidec)
Product Condition:
New
Horsepower Rating:
0.5 HP
Synchronous RPM:
1200 RPM
Rated RPM:
1130 RPM
Frame Size:
48Y
Rated Supply Voltage:
208-230 V
Motor Enclosure Type:
Totally Enclosed Air Over (TEAO)
Full Load Torque:
39.09
Rated Voltage:
208 V
Rated Voltage:
230 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
F
Duty Cycle:
Continuous
C Dimension:
10.5
Bearing Type:
6201
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
2.5 A

Product Information

US Motors (Nidec) Series

1/2 HP, 1130 RPM, 1862PEP, 208-230 V, 60 & 50 HZ, 48Y
