Technical Specifications
Model:
00736OT3E184T-S
Brand:
WEG
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
7.5 HP
Synchronous RPM:
3600 RPM
Rated Supply Voltage:
230/460 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Efficiency:
88.5%
Construction:
Rolled Steel
C Dimension:
15.157
Mounting Type:
Foot Mount
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
8.7 A
Frame Size:
182/4T
Frame Size:
182T
Frame Size:
184T
Duty Cycle:
Continuous
