Mangoldt Reactor 600 V, 5% Z, 60 HP, 67 A, 0.73 mH (ACK65-0067)
- Weight:
- 40.60 LBS
Load reactors (or output reactors) are placed between the VFD and motor, protecting motor windings from voltage spikes, smoothing current waveforms, and minimizing the damaging effects of IGBT switching.
-
-
Mangoldt Reactor 600 V, 5% Z, 50 HP, 53 A, 0.92 mH (ACK65-0053)
- Weight:
- 35.10 LBS
-
Mangoldt Reactor 480 V, 5%, 125 HP, 159 A, 0.245 mH (ACL45-0159)
- Weight:
- 77.00 LBS
-
Mangoldt Reactor 480 V, 3%, 400 HP, 480 A, 0.050 mH (ACL43-0480)
- Weight:
- 125.40 LBS
-
Mangoldt Reactor 480 V, 3%, 250 HP, 302 A, 0.08 mH (ACL43-0302)
- Weight:
- 90.64 LBS
-
Mangoldt Reactor 480 V, 3%, 75 HP, 100 A, 0.24 mH (ACL43-0100)
- Weight:
- 40.92 LBS
-
Mangoldt Reactor 600 V, 5%, 700 HP, 673 A, 0.073 mH (ACL65-0673)
- Weight:
- 268.40 LBS
-
Mangoldt Reactor 600 V, 5%, 75 HP, 81 A, 0.61 mH (ACL65-0081)
- Weight:
- 61.60 LBS
-
Mangoldt Reactor 600 V, 5%, 400 HP, 382 A, 0.130 mH (ACL65-0382)
- Weight:
- 171.60 LBS
-
Mangoldt Reactor 600 V, 5% Z, 125 HP, 131 A, 0.37 mH (ACK65-0131)
- Weight:
- 64.60 LBS
-
Mangoldt Reactor 480 V, 3%, 500 HP, 594 A, 0.040 mH (ACL43-0594)
- Weight:
- 160.82 LBS
-
Mangoldt Reactor 600 V, 5%, 7.5 HP, 9 A, 5.40 mH (ACL65-0009)
- Weight:
- 14.74 LBS
