Mangoldt Reactor 600 V, 5%, 100 HP, 106 A, 0.46 mH (ACL65-0106)
- Weight:
- 63.80 LBS
Load reactors (or output reactors) are placed between the VFD and motor, protecting motor windings from voltage spikes, smoothing current waveforms, and minimizing the damaging effects of IGBT switching.
-
-
Mangoldt Reactor 480 V, 3%, 10 HP, 14 A, 1.70 mH (ACL43-0014)
- Weight:
- 11.22 LBS
-
Mangoldt Reactor 600 V, 5%, 500 HP, 488 A, 0.100 mH (ACL65-0488)
- Weight:
- 297.00 LBS
-
Mangoldt Reactor 480 V, 3% Z, 30 HP, 43 A, 0.56 mH (ACK43-0043)
- Weight:
- 16.40 LBS
-
Mangoldt Reactor 480 V, 3%, 40 HP, 52 A, 0.46 mH (ACL43-0052)
- Weight:
- 27.00 LBS
-
Mangoldt Reactor 480 V, 5%, 300 HP, 366 A, 0.106 mH (ACL45-0366)
- Weight:
- 160.00 LBS
-
Mangoldt Reactor 480 V, 5%, 150 HP, 185 A, 0.210 mH (ACL45-0185)
- Weight:
- 90.20 LBS
-
Mangoldt Reactor 600 V, 5%, 125 HP, 129 A, 0.38 mH (ACL65-0129)
- Weight:
- 110.00 LBS
-
Mangoldt Reactor 480 V, 3%, 250 HP, 302 A, 0.08 mH (ACL43-0302)
- Weight:
- 116.00 LBS
-
Mangoldt Reactor 480 V, 5%, 250 HP, 302 A, 0.130 mH (ACL45-0302)
- Weight:
- 141.00 LBS
-
Mangoldt Reactor 480 V, 3%, 25 HP, 35 A, 0.70 mH (ACL43-0035)
- Weight:
- 20.00 LBS
-
Mangoldt Reactor 480 V, 3%, 60 HP, 81 A, 0.30 mH (ACL43-0081)
- Weight:
- 36.00 LBS
