Corro-Duty World Motor
APPLICATIONS:
For pulp & paper, mill & chemical and any other severe duty environments found in the process industries
-
- Weight:
- 490.00 LBS
-
- Model:
- CD40P2G
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 40 HP
-
- Synchronous RPM:
- 1800 RPM
-
- Rated RPM:
- 1780 RPM
-
- Frame Size:
- 324T
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 118
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 94.1%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6211-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 37 A
-
- Weight:
- 490.00 LBS
-
- Model:
- CD40P2F
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 40 HP
-
- Synchronous RPM:
- 1800 RPM
-
- Frame Size:
- 324T
-
- Rated Supply Voltage:
- 460 & 400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 118.1
-
- Rated Voltage:
- 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 94.1%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6211-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 46 A
-
- Weight:
- 460.00 LBS
-
- Model:
- CD40P1GS
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 40 HP
-
- Synchronous RPM:
- 3600 RPM
-
- Rated RPM:
- 3560 RPM
-
- Frame Size:
- 324TS
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 59
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 92.4%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6211-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 37 A
-
- Weight:
- 460.00 LBS
-
- Model:
- CD40P1FS
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 40 HP
-
- Synchronous RPM:
- 3600 RPM
-
- Frame Size:
- 324TS
-
- Rated Supply Voltage:
- 460 & 400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 59
-
- Rated Voltage:
- 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 92.4%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6211-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 46 A
-
- Weight:
- 170.00 LBS
-
- Model:
- CD3P3G
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 1200 RPM
-
- Rated RPM:
- 1180 RPM
-
- Frame Size:
- 213T
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 13.4
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 90.2%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6206-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 3.5 A
-
- Weight:
- 100.00 LBS
-
- Model:
- CD3P2G
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 1800 RPM
-
- Rated RPM:
- 1770 RPM
-
- Frame Size:
- 182T
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 8.9
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 89.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 3.1 A
-
- Weight:
- 110.00 LBS
-
- Model:
- CD3P2EC
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 1800 RPM
-
- Frame Size:
- 182TC
-
- Rated Supply Voltage:
- 230/460 & 200/400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 8.9
-
- Rated Voltage:
- 208 V, 230 V, 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 89.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 7.8/3.9 A
-
- Weight:
- 100.00 LBS
-
- Model:
- CD3P2E
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 1800 RPM
-
- Frame Size:
- 182T
-
- Rated Supply Voltage:
- 230/460 & 200/400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 8.9
-
- Rated Voltage:
- 208 V, 230 V, 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 89.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 7.8/3.9 A
-
- Weight:
- 80.00 LBS
-
- Model:
- CD3P1G
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 3600 RPM
-
- Rated RPM:
- 3540 RPM
-
- Frame Size:
- 182T
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 4.4
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 86.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 3.3 A
-
- Weight:
- 90.00 LBS
-
- Model:
- CD3P1EC
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 3600 RPM
-
- Frame Size:
- 182TC
-
- Rated Supply Voltage:
- 230/460 & 200/400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 4.4
-
- Rated Voltage:
- 208 V, 230 V, 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 86.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 8.2/4.1 A
-
- Weight:
- 80.00 LBS
-
- Model:
- CD3P1E
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 3 HP
-
- Synchronous RPM:
- 3600 RPM
-
- Frame Size:
- 182T
-
- Rated Supply Voltage:
- 230/460 & 200/400 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 4.4
-
- Rated Voltage:
- 208 V, 230 V, 460 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 86.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz, 50 Hz
-
- Motor Full Load Amps:
- 8.2/4.1 A
-
- Weight:
- 100.00 LBS
-
- Model:
- CD32P3G
-
- Brand:
- US Motors (Nidec)
-
- Product Condition:
- New
-
- Motor Type:
- Severe Duty
-
- Horsepower Rating:
- 1.5 HP
-
- Synchronous RPM:
- 1200 RPM
-
- Rated RPM:
- 1180 RPM
-
- Frame Size:
- 182T
-
- Rated Supply Voltage:
- 575 V
-
- Motor Enclosure Type:
- Totally Enclosed Fan Cooled (TEFC)
-
- Motor Design Class:
- B
-
- Full Load Torque:
- 6.7
-
- Rated Voltage:
- 575 V
-
- Phase:
- Three Phase
-
- Service Factor:
- 1.15
-
- Insulation Class:
- F
-
- Duty Cycle:
- Continuous
-
- Efficiency:
- 87.5%
-
- Construction:
- Cast Iron
-
- Bearing Type:
- 6205-J/C3
-
- Rated Input Frequency:
- 60 Hz
-
- Motor Full Load Amps:
- 1.8 A
