40HP at 460V, 20HP at 230V, WEG Soft Starter, SSW050060T2246EPZ (SSW050060T2246EPZ)

40HP at 460V, 20HP at 230V, WEG Soft Starter, SSW050060T2246EPZ (SSW050060T2246EPZ)

Brand:
WEG
Model:
SSW050060T2246EPZ
Condition:
New
0 Customer Reviews
VFDs.com Guarantee Badge
Out Of Stock
Call for Price
Adding to cart… The item has been added
  • 208 - 480V, 50/60Hz input power supply
  • Duty cycle: 300% rated current during 10 seconds, 4 starts per hour
  • Built-in bypass
  • One digital input for Start/Stop (90 - 250 Vac)
  • One digital input for Fault Reset (90 - 250 Vac)
  • One relay output for Run indication (1 Amp - 250V)
  • One relay output for Full Voltage indication (1 Amp - 250V)
  • RS-232 serial port
  • Adjustable acceleration and deceleration ramps (1 - 20 seconds)
  • Adjustable pedestal voltage (30 - 80% of line voltage)
  • Protective features: Motor overload, over current and locked rotor, SCR overload, phase loss and phase sequence
  • DIN rail or direct mount
  • Ambient: 32ºF (0ºC) to 131ºF (55ºC), 3300ft (1000m) altitude, 90% non-condensing humidity
    • Write a Review

    Technical Specifications

    Product Information

    WEG Series

    A Cost-Effective Soft Starter with a Brand Name You Can Trust

    Standard Features

    RVSS Details

    Manufacturer
    WEG

    Series
    SSW05

    Model
    SSW050060T2246EPZ

    Condition
    New

    Horse Power at 230V
    20 HP

    Horse Power at 460V
    40 HP

    Maximum Amps
    60 A

    Input
    3-Phase
    230-460V

    Output
    3-Phase
    230-460V

    Enclosure
    IP00

    Dimensions
    Height: 7.3 in
    Width: 3.1 in
    Depth: 6.8 in
